Production of glucose syrup from cassava starch

Release Time:2020-07-20 19:02Author:sd888Source:未知

Any questions about the product can be communicated with us at any time!

Service Phone:0086 371 26630769
Liquefaction:
Cassava starch slurry is made with 30-35% dry solids and adjust its PH value to 6.0-6.4. Calcium is added using calcium hydroxide or calcium chloride because calcium ions can stabilize the enzyme. A heat-stable α-amylase (Novo’s Termamyl 120L) is mixed into the cassava starch slurry, then the slurry is instantaneously heated to 100 ℃ and held at this temperature for 10 min before it is cooled to 90 ℃. This temperature is maintained for 1-3h to further hydrolyze the starch. Among this, it is the manufacturing process of liquefaction process in the production of glucose syrup from cassava starch.
After this liquefying step complete, the starch has been transfered into dextrins with a dextrose equivalent (DE) between 8 and 15. (The physical properties of the syrup changed with the DE and the method of manufacture difference.) DE is the total reducing sugar in the syrup expressed as dextrose on a dry weight basis.
Production-of-glucose-syrup-from-cassava-starch
Saccharification:
After liquefaction, the pH is reduced to between 4.2 and 4.5 and the solution is cooled to 60 ℃. A glucomylase (Novo’s AMG 300L) is added immediately. The reaction time for saccharification is usually between 24-48 h depending on enzyme does. Glucoamylase releases single glucose units from the ends of dextrin molecule. Syrups of 95% glucose or higher are manufactured. This is the saccharification process for the production of glucose syrup from cassava starch.
It's worth to tell you the liquefaction and saccharification step is the most important two parts of the glucose syrup production from glucose syrup. These steps performance influenced and decided the glucose products quality directly. So the advanced technology and equipments used for the production of glucose syrup from cassava starch select is very important.

Purification in the production of glucose syrup from cassava starch:
Purification step in the glucose syrup production is mean the last evaporating process to remove excess moisture from glucose, to get a standard concentration. On the other side, it also include the glucose syrup decolorization process, if you want to get colorless and transparent glucose, sida Company plate and frame filter press can remove the color from syrup to meet your requests, if you don't request the glucose syrup colorless, don't need this. Purification process also include the ion exchange system for the production of glucose syrup from cassava starch, it's function is fully remove the ions to get pure syrup, widely used and suitable for all kinds of syrup production. By the way, this is the content in purification for the production of glucose syrup from cassava starch.
For another, native starch consists of microscopic granules which with a complex internal structure. Under room temperature, these granules are insoluble in water. However, if a starch slurry is heated above 60 ℃, the granules will swell and rupture at last. This results in a dramatic increase in the cassava starch slurry viscosity. At this point, the cassava starch has been “gelatinized”. The gelatinized starch is now susceptible to attack by amylase enzymes. In practice, cassava starch in gelatinized and partially hydrolyzed very rapidly in one step (see flow chart) by heat-stable amylase.
